Key Features
- RISC-V core @ 108 MHz
- Flash access 0~2 wait states
- Single-cycle multiplier and multi-cycle hardware divider
- Up to 68 maskable peripheral Interrupts, with 16 priority levels
- Flash size up to 128KB
- SRAM size up to 32KB
- Three power saving modes: Sleep, Deep-sleep and Standby modes
- 2x 12bit, 1μs ADC (up to 16 chs)
- 2x 12bit DAC
- Up to 3x USART, 2x UART, Irda/LIN/ISO7816-3
- Up to 3x SPI
- 2 x I2S
- Up to 2x I2C
- 1x 16 bit Advanced Timer
- 4x 16 bit GPTM
- 1x 24bit SysTick Timer, 2x 16 bit Basic Timer, 2x WDG, 1x RTC
- 12-chs DMA supported
- POR,PDR,LVD
- 80% GPIO available
- 32-bit CRC
- On-chip clock: HSI (8MHz & 25MHz)
- External Memory Control supported: SRAM, PSRAM, NOR-Flash, ROM
